Tumble Type & Turn table type shot blasting machine manufactured by us are available in specific chamber sizes. The design and fabrication of these machines are backed by a decade of experience. we have been successful in developing these machines through sustained research & development works and we can say that these are best available in the market.
Technical Specification for Shot Blasting Machine Turn Table Type
Model | Chamber Size | Machine Dimensions LxWxH | Table Drive | Rotor Drive Motor | Blower Drive Motor | Elevator Drive Motor | Rotor Dia | Batch Capacity | WT.OF Machine (Approx) | Type Of Dust Collector |
| RSHB-C 48″ | 73″X44″ | 99″X75″X54″ | 1.0 H.P. | 12.5 H.P. | 3.0. H.P. | 2.0 H.P. | 482 MM | 400-500 Kg | 6500 Kg | Dry Type |
| RSHB-C 72″ | 93″X73″ | 134″X105″X180″ | 2.0 H.P. | 15 H.P. | 5.0 H.P. | 2.0 H.P. | 482 MM | 1000-1200 Kg | 9000 Kg | Dry Type |
| RSHB-C 96″ | 121″X10 | 156″X130″X105″ | 2.0 H.P. | 15 H.P. | 5.0 H.P | 2.0 H.P. | 482 MM | 1200-1500 Kg | 12500 Kg | Dry Type |
